1.Product name:
Tecumseh Reciprocating Compressor
2.Model number:
CAJ9510T-F1 F VATC ,220~240V/50hz,Working R22 refrigerant,Screw connection,1HP
MBP/HBP application
3.Product specification
| Refrigeration Capacity | Input Power | ||||
| Condition | Test Voltage | Btu/h | kcal/h | W | W |
| EN12900 ASERCOM | 230V ~ 50HZ | 4307 | 1085 | 1262 | 749 |
| Efficiency | EVAP TEMP | COND TEMP | AMBIENT TEMP | RETURN GAS | LIQUID TEMP | ||
| Btu/Wh | kcal/Wh | W/W | |||||
| 5.75 | 1.45 | 1.68 | -10°C (14°F) | 45°C (113°F) | 32°C (90°F) | 0°C (32°F) | 45°C (113°F) |
4. General
| Evaporating Temp. Range: | -23.3°C to 12.8°C (-10°F to 55°F) |
| Motor Torque: | High Start Torque (HST) |
| Compressor Cooling: | Fan |
5. Mechanical
| Weight: | 22.922 |
| Weight Unit of Measure: | N/A |
| Displacement (cc): | 18.3 |
| Oil Type: | Mineral |
| Viscosity (cSt): | 68 |
| Oil Charge (cc): | 887 |
| Sound Power dB(A): | N/A |
6. Electrical
| Voltage Range (50 Hz): | 198-253 |
| Voltage Range (60 Hz): | N/A |
| Locked Rotor Amps (LRA): | 29 |
| Rated Load Amps (RLA 50 Hz): | 4.7 |
| Rated Load Amps (RLA 60 Hz): | 4.7 |
| Max. Continuous Current (MCC in Amps): | 7.5 |
| Motor Resitance (Ohm) - Main: | 2.4 |
| Motor Resitance (Ohm) - Start: | 10.3 |
| Motor Type: | CSR |
| Overload Type: | EXTERNAL |
| Relay Type: | Potential Relay |
7.Other available R22 MBP/HBP models
| 1 | AEZ3440E-F2 FTU | R22 | 1/3 HP |
| 2 | CAE9460T-F2 FTU | R22 | 1/2 HP |
| 3 | AJ5510F-F1 F PSC TU | R22 | 3/4 HP |
| 4 | AJ5518E-F1 F CSR TU | R22 | 1-1/4 HP |
| 5 | CAE2420E-F2 GTU | R22 | 1/2 HP |
| 6 | CAJ9480T-F1 F VATC | R22 | 5/8 HP |
| 7 | CAJ9510T-F1 F VATC | R22 | 1 HP |
| 8 | CAJ9513T-F1 F VATC | R22 | 1-1/8 HP |
| 9 | CAJ9513T-F1 TU | R22 | 1-1/8 HP |
| 10 | CAJ4517E-F1 F VA TC | R22 | 1-1/4 HP |
| 11 | TAJ9510T-F1 F TU | R22 | 1 HP |
| 12 | CAJ4519T-F1 G VA TC | R22 | 1-3/4 HP |
| 13 | CAJ4519T-F1 G TU | R22 | 1-3/4 HP |
| 14 | CAJ2427E-F1 G TU | R22 | 3/4 HP |
| 15 | CAJ2439E-F1 G TU | R22 | 1 HP |
| 16 | TAJ9510T-F1 F VA TC | R22 | 1 HP |
| 17 | CAJ9480T-F1 F TU | R22 | 5/8 HP |
| 18 | CAJ9510T-F1 F TU | R22 | 1 HP |
| 19 | AJ5512E-F1 G PSC TU | R22 | 1 HP |
| 20 | AJ5515E-F1 G PSC TU | R22 | 1-1/4 HP |
8.Warehouse Pictures.
