• Place of Origin:Jiangsu, China
• Brand Name:Elitech
• Model Number:STC-9200
• Temperature measuring:-50~50°C
• Power supply::220VAC ± 10% 50HZ / 60HZ
• Power consumption of the whole machine::<5W
• Ambient temperature::0 ℃ ~ + 60 ℃
• Relative humidity::20% ~ 85% non-condensing
• emperature measurement accuracy::± 1 ℃
• Compressor relay capacity::8A / 220VAC

Features:
Main Functions and Features
Dual control of refrigeration, time and temperature
User parameter and manager parameter are set separately, user set parameter value upper and lower limit function
Multiple defrost and fan management methods
Defrosting drip time can be set
With copy card function, it is convenient to quickly set parameters during mass production and after-sales service, saving man-hours and reducing after-sales service expenses.

Second, the main technical parameters:
1. Temperature measurement range: -50-50 ° C Temperature control range: -50-50 °
2. Power supply voltage: 220VAC ± 10% 50HZ / 60HZ
3. Power consumption of the whole machine: <5W
4. Ambient temperature: 0 ℃ ~ + 60 ℃
5. Relative humidity: 20% ~ 85% non-condensing
6. Temperature measurement accuracy: ± 1 ℃ Display resolution: 0.1 ℃
7. Compressor relay capacity: 8A / 220VAC
8. Fan and defrosting relay capacity: 8A / 220VAC
9. Digital display: three-digit digital tube + negative sign + status indicator

Third, the indicator
The meaning of the indicator status indicates that the refrigeration indicator is off, the compressor is stopped, the refrigeration indicator is blinking, the compressor is delayed, the refrigeration indicator is on, and the compressor is working. The frost indicator lights up the defrosting work. The defrost indicator flashes quickly to force the defrosting fan indicator to turn off the fan. The fan stops to blink. The fan blinks.
Fourth, the key functions and settings
