Working conditions:
1.1,Power supply:230VAC±10% 50/60Hz
1.2,Rated current of relays:8A/220VAC
1.3,Ambient temperature:-15℃~60℃ Relative humidity:20%~85% (No condensate)
1.4,Storage temperature:-15℃~60℃
Specification:
2.1,Product:Length 77× Width 34.5 × Depth 58(mm)
2.2,Mounting size:Length 71 × Width 29 (mm)
2.3,Sensor wire length:2M(including the sensor)
Technical parameters:
3.1,Temperature controlling range:-50℃~99℃
3.2,Display resolution:1℃/0.1℃(With the switch mode between integer and decimal )
3.3,Accuracy:NTC:±0.5℃(-30℃-50℃),others,±1℃
PTC:±2℃(-30℃-50℃),others, ±3℃
3.4,Sensor type:NTC(-50℃~120℃) PTC(-50℃~150℃)1, Working conditions:
1.1,Power supply:230VAC±10% 50/60Hz
1.2,Rated current of relays:8A/220VAC
1.3,Ambient temperature:-15℃~60℃ Relative humidity:20%~85% (No condensate)
1.4,Storage temperature:-15℃~60℃
Specification:
2.1,Product:Length 77× Width 34.5 × Depth 58(mm)
2.2,Mounting size:Length 71 × Width 29 (mm)
2.3,Sensor wire length:2M(including the sensor)
Technical parameters:
3.1,Temperature controlling range:-50℃~99℃
3.2,Display resolution:1℃/0.1℃(With the switch mode between integer and decimal )
3.3,Accuracy:NTC:±0.5℃(-30℃-50℃),others,±1℃
PTC:±2℃(-30℃-50℃),others, ±3℃
3.4,Sensor type:NTC(-50℃~120℃) PTC(-50℃~150℃)
